SPECIFICATIONS (Cont.)
All specifications at +25°C, +VCC = +5V, +VDD = +3.3V, system clock = 384fS (fS = 44.1kHz) and 24-bit data, unless otherwise noted.
PCM1600Y, PCM1601Y
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
POWER SUPPLY REQUIREMENTS
Voltage Range, VDD
VCC
+3.0
+4.5
+3.3
+5.0
20
+3.6
+5.5
28
V
V
(7)
Supply Current, IDD
fS = 44.1kHz
fS = 96kHz
fS = 44.1kHz
fS = 96kHz
fS = 44.1kHz
fS = 96kHz
mA
mA
mA
mA
mW
mW
42
ICC
40
56
42
266
349
Power Dissipation
409
TEMPERATURE RANGE
Operation
0
+70
°C
°C
Storage
–55
+125
Thermal Resistance, θJA
100
°C/W
NOTES: (1) Pins 38, 40, 41, 45-47 (SCLKI, BCK, LRCK, DATA1, DATA2, DATA3). (2) Pins 34-37 (MDI, MC, ML, RST). (3) Pins 1-6, 48 (ZERO1-6, ZEROA).
(4) Pin 39 (SCLKO). (5) Analog performance specifications are tested with Shibasoku #725 THD Meter 400Hz HPF, 30kHz LPF on, average mode with 20kHz
bandwidth limiting. The load connected to the analog output is 5kΩ or larger, AC-coupled. (6) SNR is tested with Infinite Zero Detection off. (7) CLKO is disabled.
ABSOLUTE MAXIMUM RATINGS
ELECTROSTATIC
Power Supply Voltage, VDD .............................................................. +4.0V
VCC .............................................................. +6.5V
DISCHARGE SENSITIVITY
+VCC to +VDD Difference ................................................................... ±0.1V
Digital Input Voltage ........................................................... –0.2V to +5.5V
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
Digital Output Voltage(1) ........................................... –0.2V to (VDD + 0.2V)
Input Current (except power supply) ............................................... ±10mA
Power Dissipation .......................................................................... 650mW
Operating Temperature Range ............................................. 0°C to +70°C
Storage Temperature ...................................................... –55°C to +125°C
Lead Temperature (soldering, 5s) ................................................ +260°C
Package Temperature (IR reflow, 10s) .......................................... +235°C
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
NOTE: (1) Pin 33 (MDO) when output is disabled.
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING
NUMBER
SPECIFIED
TEMPERATURE
RANGE
PACKAGE
MARKING
ORDERING
NUMBER(1)
TRANSPORT
MEDIA
PRODUCT
PACKAGE
PCM1600Y
48-Lead LQFP
340
"
0°C to +70°C
PCM1600Y
PCM1600Y
PCM1600Y/2K
PCM1601Y
250-Piece Tray
Tape and Reel
84-Piece Tray
Tape and Reel
"
"
"
"
PCM1601Y
48-Lead MQFP
359
0°C to +70°C
PCM1601Y
"
"
"
"
"
PCM1601Y/1K
NOTE: (1) Models with a slash (/) are available only in Tape and Reel in the quantities indicated (e.g., /2K indicates 2000 devices per reel). Ordering 2000 pieces
of “PCM1600Y/2K” will get a single 2000-piece Tape and Reel.
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
3
