ABSOLUTE MAXIMUM RATINGS
ELECTROSTATIC
Power Supply .............................................................................. ±6.5VDC
Internal Power Dissipation(1) ............................ See Thermal Information
Differential Input Voltage .................................................................. ±1.2V
Input Voltage Range............................................................................ ±VS
Storage Temperature Range: P, U, N ...........................–40°C to +125°C
Lead Temperature (soldering, 10s).............................................. +300°C
Junction Temperature (TJ ) ........................................................... +175°C
DISCHARGE SENSITIVITY
Electrostatic discharge can cause damage ranging from perfor-
mancedegradationtocompletedevicefailure. Burr-BrownCorpo-
rationrecommendsthatallintegratedcircuitsbehandledandstored
using appropriate ESD protection methods.
NOTE:: (1) Packages must be derated based on specified θJA. Maximum TJ
must be observed.
ESD damage can range from subtle performance degradation to
complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes
could cause the device not to meet published specifications.
PIN CONFIGURATION
Top View
SOT23-6
Top View
DIP/SO-8
Output
–VS
1
2
3
6
5
4
+VS
DIS
NC
1
2
3
4
8
7
6
5
DIS
Non-Inverting Input
Inverting Input
Inverting Input
+VS
Non-Inverting Input
–VS
Output
NC
6
5
4
A81
3
NC = No Connection
1
2
Pin Orientation/Package Marking
PACKAGE/ORDERING INFORMATION
PACKAGE
SPECIFIED
DRAWING
NUMBER(1)
TEMPERATURE
RANGE
PACKAGE
MARKING
ORDERING
NUMBER
TRANSPORT
PRODUCT
PACKAGE
MEDIA
OPA681P
8-Pin Plastic DIP
006
182
"
–40°C to +85°C
OPA681P
OPA681P
OPA681U
Rails
OPA681U
SO-8 Surface Mount
–40°C to +85°C
OPA681U
Rails
"
"
"
"
A81
"
OPA681U/2K5
OPA681N/250
OPA681N/3K
Tape and Reel
Tape and Reel
Tape and Reel
OPA681N
"
6-Lead SOT23-6
"
332
"
–40°C to +85°C
"
NOTES: (1) For detailed drawing and dimension table, please see end of data sheet, or Appendix C of Burr-Brown IC Data Book. (2) Models with a slash (/) are available
only as Tape and Reel in the quantity indicated after the slash (e.g. /2K5 indicates 2500 devices per reel). Ordering 3000 pieces of the OPA681N/3K will get a single
3000-piece Tape and Reel. For detailed Tape and Reel mechanical information, refer to Appendix B of the Burr-Brown IC Data Book.
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
