PIN CONFIGURATION
ABSOLUTE MAXIMUM RATINGS
Top View
8-Pin DIP/SOIC
Supply Voltages: VS1, VS2 ......................................................... 0V to 5.5V
Steady-State Input Voltage .......................................... –2V to VS1 + 0.5V
2 Second Transient Input Voltage ................................................... –6.0V
Output Voltages: VOUT+, VOUT– ................................... –0.5V to VS2 + 0.5V
Lead Temperature Solder (1.6mm below seating plane, 10s) ....... 260°C
VS1
1
2
3
4
8
7
6
5
VS2
VIN
+
–
VOUT
VOUT
+
–
PACKAGE INFORMATION(1)
VIN
PACKAGE DRAWING
GND1
GND2
MODEL
PACKAGE
NUMBER
ISO130P
ISO130PB
ISO130U
ISO130UB
8-Pin Plastic DIP
8-Pin Plastic DIP
8-Pin Gull-Wing Plastic Surface Mount
8-Pin Gull-Wing Plastic Surface Mount
006-3
006-3
006-2
006-2
NOTE: (1) For detailed drawing and dimension table, please see end of data
sheet, or Appendix D of Burr-Brown IC Data Book.
ELECTROSTATIC
DISCHARGE SENSITIVITY
ORDERING INFORMATION
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with ap-
propriate precautions. Failure to observe proper handling and
installation procedures can cause damage.
GAIN ERROR
MODEL
PACKAGE
(MAX)
ISO130P
ISO130PB
ISO130U
8-Pin Plastic DIP
8-Pin Plastic DIP
8-Pin Gull-Wing Plastic Surface Mount ±5% (mean value = 8.00)
±5% (mean value = 8.00)
±1% (mean value = 7.93)
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
ISO130UB 8-Pin Gull-Wing Plastic Surface Mount ±1% (mean value = 7.93)
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
ISO130
