High Voltage MLC Radials (SV Style)
CAPACITANCE VALUE
C0G
Style
600/630V
min./max.
1000V
min./max.
1500V
min./max.
2000V
2500V
min./max.
3000V
min./max.
4000V
min./max.
5000V
min./max.
min./max.
SV01
100 pF/ 1500 pF 100 pF / 1000 pF
100 pF/ 6800 pF 100 pF / 4700 pF 100 pF / 1500 pF
100 pF/0.012 μF 100 pF / 8200 pF 100 pF / 2700 pF 100 pF/ 1800 pF
100 pF/ 3900 pF 100 pF / 2700 pF 10 pF / 820 pF 10 pF/ 560 pF
10 pF / 330 pF
10 pF/ 220 pF
10 pF/ 1000 pF
10 pF / 120 pF
10 pF / 680 pF
10 pF /1000 pF
10 pF / 270 pF
10 pF / 82 pF
10 pF / 560 pF
10 pF / 680 pF
10 pF / 180 pF
—
—
SV02/SV52
SV03/SV53
SV04/SV54
10 pF / 150 pF
10 pF / 390 pF
10 pF / 100 pF
10 pF /1000 pF
10 pF / 470 pF
10 pF / 100 pF
10 pF / 220 pF
10 pF / 68 pF
10 pF / 560 pF
10 pF / 390 pF
10 pF /1200 pF
SV05/SV55 1000 pF/0.027 μF 1000 pF / 0.018 μF 100 pF / 6800 pF 100 pF/ 4700 pF 100 pF /2700 pF 100 pF / 1500 pF
SV06/SV56 100 pF/0.012 μF 100 pF / 0.010 μF 100 pF / 3300 pF 100 pF/ 2200 pF 10 pF /1200 pF 10 pF / 820 pF
SV07/SV57 1000 pF/0.056 μF 1000 pF / 0.033 μF 1000 pF /0.015 μF 100 pF/0.010 μF 100 pF /5600 pF 100 pF / 3900 pF 100 pF /2200 pF
SV08/SV58 1000 pF/0.082 μF 1000 pF / 0.047 μF 1000 pF /0.022 μF 1000 pF/0.015 μF 100 pF /0.010 μF 100 pF / 6800 pF 100 pF /3300 pF 100 pF /2200 pF
SV09/SV59 1000 pF/0.150 μF 1000 pF / 0.082 μF 1000 pF /0.039 μF 1000 pF/0.022 μF 1000 pF /0.015 μF 100 pF / 8200 pF 100 pF /4700 pF 100 pF /3300 pF
SV10
SV11
SV12
1000 pF/0.100 μF 1000 pF / 0.056 μF 1000 pF /0.022 μF 1000 pF/0.012 μF 100 pF /8200 pF 100 pF / 5600 pF 100 pF /3300 pF 100 pF /2200 pF
1000 pF/0.150 μF 1000 pF / 0.082 μF 1000 pF /0.039 μF 1000 pF/0.022 μF 1000 pF /0.015 μF 100 pF / 8200 pF 100 pF /4700 pF 100 pF /3300 pF
0.01 μF/0.220 μF 0.01 μF / 0.15 μF 1000 pF /0.056 μF 1000 pF/0.033 μF 1000 pF /0.022 μF 1000 pF /0.015 μF 100 pF /8200 pF 100 pF /5600 pF
SV13/SV63
100 pF/0.018 μF 100 pF / 0.012 μF 100 pF / 4700 pF 100 pF/ 2700 pF 100 pF /1800 pF 100 pF / 1000 pF
10 pF / 470 pF
10 pF / 820 pF
10 pF / 390 pF
10 pF / 680 pF
SV14/SV64 1000 pF/0.039 μF 1000 pF / 0.022 μF 100 pF / 8200 pF 100 pF/ 5600 pF 100 pF /3300 pF 100 pF / 1800 pF
SV15/SV65 1000 pF/0.056 μF 1000 pF / 0.033 μF 1000 pF /0.015 μF 100 pF/ 0.01 μF 100 pF /5600 pF 100 pF / 2700 pF 100 pF /1800 pF 100 pF /1200 pF
SV16/SV66 1000 pF/0.120 μF 1000 pF / 0.082 μF 1000 pF /0.039 μF 1000 pF/0.027 μF 1000 pF /0.015 μF 100 pF / 8200 pF 100 pF /4700 pF 100 pF /3300 pF
SV17/SV67 1000 pF/0.150 μF 1000 pF / 0.10 μF 1000 pF /0.056 μF 1000 pF/0.039 μF 1000 pF /0.022 μF 1000 pF /0.012 μF 100 pF /6800 pF 100 pF /4700 pF
X7R
SV01
1000 pF/0.018 μF 1000 pF / 0.012 μF 100 pF / 5600 pF 100 pF/ 3900 pF
—
—
—
—
—
—
—
—
—
SV02/SV52 1000 pF/0.082 μF 1000 pF / 0.047 μF 1000 pF /0.015 μF 100 pF/ 6800 pF 100 pF /3900 pF 100 pF / 2700 pF
SV03/SV53 1000 pF/0.180 μF 1000 pF / 0.082 μF 1000 pF /0.018 μF 1000 pF/ 0.01 μF 100 pF /6800 pF 100 pF / 4700 pF 100 pF /1800 pF
SV04/SV54 1000 pF/0.056 μF 1000 pF / 0.033 μF 100 pF / 6800 pF 100 pF/ 3900 pF 100 pF /2200 pF 100 pF / 1800 pF 100 pF / 820 pF
SV05/SV55 0.01 μF/0.470 μF 0.01 μF / 0.22 μF 1000 pF /0.056 μF 1000 pF/0.027 μF 1000 pF /0.018 μF 1000 pF /0.012 μF 100 pF /4700 pF
SV06/SV56 0.01 μF/0.180 μF 0.01 μF / 0.10 μF 1000 pF /0.033 μF 1000 pF/0.012 μF 100 pF /8200 pF 100 pF / 6800 pF 100 pF /2700 pF 100 pF /1200 pF
SV07/SV57 0.01 μF/0.820 μF 0.01 μF / 0.39 μF 0.01 μF / 0.10 μF 1000 pF/0.047 μF 1000 pF /0.033 μF 1000 pF /0.027 μF 1000 pF / 0.01 μF 100 pF /6800 pF
SV08/SV58 0.01 μF/ 1.20 μF 0.01 μF / 0.68 μF 0.01 μF / 0.18 μF 1000 pF/0.082 μF 1000 pF /0.068 μF 1000 pF /0.047 μF 1000 pF /0.018 μF 1000 pF /0.012 μF
SV09/SV59 0.10 μF/ 1.80 μF 0.10 μF / 1.00 μF 0.01 μF / 0.27 μF 0.01 μF/ 0.12 μF 0.01 μF / 0.10 μF 1000 pF /0.068 μF 1000 pF /0.027 μF 1000 pF /0.018 μF
SV10
SV11
SV12
0.01 μF/ 1.50 μF 0.01 μF / 0.82 μF 0.01 μF / 0.22 μF 0.01 μF/ 0.10 μF 1000 pF /0.082 μF 1000 pF /0.056 μF 1000 pF /0.022 μF 1000 pF /0.022 μF
0.10 μF/ 2.20 μF 0.10 μF / 1.2 μF 0.01 μF / 0.39 μF 0.01 μF/ 0.18 μF 0.01 μF / 0.15 μ
F
F
F
0.01 μF / 0.10 μF 1000 pF /0.039 μF 1000 pF /0.027 μF
0.01 μF / 0.15 μF 1000 pF /0.056 μF 1000 pF /0.033 μF
0.10 μF/ 3.90 μF 0.10 μF / 2.20 μF 0.01 μF / 0.56 μF 0.01 μF/ 0.27 μF 0.01 μF / 0.22 μ
SV13/SV63 0.01 μF/0.270 μF 0.01 μF / 0.10 μF 1000 pF /0.033 μF 1000 pF/0.012 μF 1000 pF / 0.01 μ
SV14/SV64 0.01 μF/0.470 μF 0.01 μF / 0.18 μF 1000 pF /0.068 μF 1000 pF/0.022 μF 1000 pF /0.018 μF 1000 pF /0.015 μF 100 pF /5600 pF
100 pF / 6800 pF 100 pF /2700 pF
—
—
SV15/SV65 0.01 μF/0.680 μF 0.01 μF / 0.33 μF 0.01 μF / 0.10 μF 1000 pF/0.033 μF 1000 pF /0.027 μF 1000 pF /0.022 μF 1000 pF /8200 pF 100 pF /4700 pF
SV16/SV66 0.01 μF/ 1.80 μF 0.01 μF / 1.0 μF 0.01 μF / 0.27 μF 0.01 μF/ 0.12 μF 0.01 μF / 0.10 μF 1000 pF /0.068 μF 1000 pF /0.027 μF 1000 pF /0.018 μF
SV17/SV67 0.01 μF/ 2.20 μF 0.01 μF / 1.2 μF 0.01 μF / 0.39 μF 0.01 μF/ 0.15 μF 0.01 μF / 0.12 μF 1000 pF /0.082 μF 1000 pF /0.039 μF 1000 pF /0.027 μF
Note: Contact factory for other voltage ratings or values.
AVX IS QUALIFIED TO THE FOLLOWING DSCC DRAWINGS
Specification #
Description
C0G-1000 VDC
X7R-1000 VDC
X7R-2000 VDC
C0G-3000 VDC
X7R-3000 VDC
C0G-4000 VDC
X7R-4000 VDC
C0G-5000 VDC
X7R-5000 VDC
Capacitance Range
10 pF - 0.025 μF
100 pF - 0.47 μF
100 pF - 0.22 μF
10 pF - 8200 pF
100 pF - 0.1 μF
10 pF - 6800 pF
100 pF - 0.056 μF
10 pF - 5600 pF
100 pF - 0.033 μF
87046
87043
87040
87114
87047
87076
89044
87077
87070
These specifications require group A and B testing per MIL-PRF-49467
Note: Customers may accept, at their discretion, a certificate of compliance with group B requirements in lieu of performing group B tests.
