High Voltage MLC Radials (SV Style)
L
L
T
H
H
H + 3.683
(0.145)
31.75
(1.25)
MIN
31.75
(1.250)
min.
LD
LD
S
S
SV01 thru SV17
SV52 thru SV59 and SV63 thru SV67
HIGH VOLTAGE RADIAL LEAD
HOW TO ORDER
AVX Styles: SV01 THRU SV67
SV01
A
A
102
K
A
A
*
AVX
Style
Voltage
600V/630V = C
1000V = A
1500V = S
2000V = G
2500V = W
3000V = H
4000V = J
Temperature
Coefficient
C0G = A
Capacitance Code
(2 significant digits
+ no. of zeros)
Examples:
10 pF = 100
100 pF = 101
1,000 pF = 102
22,000 pF = 223
220,000 pF = 224
1 μF = 105
Capacitance
Tolerance
C0G: J = 5ꢀ
K = 10ꢀ
M = 20ꢀ
X7R: K = 10ꢀ
M = 20ꢀ
Packaging
Test
Leads
(See Note 1)
Level
A = Tin/Lead
A = Standard R = RoHS
X7R = C
Compliant
B = Hi-Rel
*
Note 1: No suffix signifies bulk packaging
which is AVX standard packaging.
Use suffix “TR1” if tape and reel is
required. Parts are reel packaged
per EIA-468.
Z = +80 -20ꢀ
5000V = K
Note: Capacitors with X7R dielectrics are not intended for applications across
AC supply mains or AC line filtering with polarity reversal. Contact plant for
recommendations.
Hi-Rel screening consists of 100ꢀ Group A, Subgroup 1 per MIL-PRF-49467.
*
(Except partial discharge testing is not performed and DWV is at 120ꢀ rated voltage).
DIMENSIONS
millimeters (inches)
Length (L) Height (H) Thickness (T) Lead Spacing
LD (Nom)
AVX Style
max
max
max
.762 (.030) (S)
TAPE & REEL QUANTITY
RoHS
SV01
6.35 (0.250) 5.59 (0.220) 5.08 (0.200)
4.32 (0.170)
5.59 (0.220)
6.99 (0.275)
7.62 (0.300)
9.52 (0.375)
10.16 (0.400)
12.1 (0.475)
14.6 (0.575)
17.1 (0.675)
22.9 (0.900)
27.9 (1.100)
33.0 (1.300)
5.08 (0.200)
5.08 (0.200)
10.2 (0.400)
20.1 (0.790)
20.3 (0.800)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.64 (0.025)
0.51 (0.020)
0.51 (0.020)
0.64 (0.025)
0.81 (0.032)
0.81 (0.032)
Part
Pieces
1000
1000
1000
1000
1000
500
Part
Available
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
SV02/SV52 8.13 (0.320) 7.11 (0.280) 5.08 (0.200)
SV03/SV53 9.40 (0.370) 7.62 (0.300) 5.08 (0.200)
SV04/SV54 11.4 (0.450) 5.59 (0.220) 5.08 (0.200)
SV05/SV55 11.9 (0.470) 10.2 (0.400) 5.08 (0.200)
SV06/SV56 14.0 (0.550) 7.11 (0.280) 5.08 (0.200)
SV07/SV57 14.5 (0.570) 12.7 (0.500) 5.08 (0.200)
SV08/SV58 17.0 (0.670) 15.2 (0.600) 5.08 (0.200)
SV09/SV59 19.6 (0.770) 18.3 (0.720) 5.08 (0.200)
SV01
SV01
SV02/SV52
SV03/SV53
SV04/SV54
SV05/SV55
SV06/SV56
SV07/SV57
SV08/SV58
SV09/SV59
SV10
SV02/SV52
SV03/SV53
SV04/SV54
SV05/SV55
SV06/SV56
SV07/SV57
SV08/SV58
SV09/SV59
SV10
500
500
500
SV10
SV11
SV12
26.7 (1.050) 12.7 (0.500) 5.08 (0.200)
31.8 (1.250) 15.2 (0.600) 5.08 (0.200)
36.8 (1.450) 18.3 (0.720) 5.08 (0.200)
N/A
SV11
N/A
SV11
No
SV12
N/A
SV12
No
SV13/SV63 7.62 (0.300) 9.14 (0.360) 5.08 (0.200)
SV14/SV64 10.2 (0.400) 11.7 (0.460) 5.08 (0.200)
SV15/SV65 12.7 (0.500) 14.2 (0.560) 5.08 (0.200)
SV16/SV66 22.1 (0.870) 16.8 (0.660) 5.08 (0.200)
SV17/SV67 23.6 (0.930) 19.8 (0.780) 6.35 (0.250)
SV13/SV63
SV14/SV64
SV15/SV65
SV16/SV66
SV17/SV67
1000
1000
500
SV13/SV63
SV14/SV64
SV15/SV65
SV16/SV66
SV17/SV67
Yes
Yes
Yes
Yes
Yes
500
400
67
