Reel Dimensions and Orientation
BACK VIEW
Shading indicates
thru slots
18.4 max.
+0.4
-0.2
178
50 min.
25
min wide (ref)
Slot for carrier
tape insertion
for attachment
to reel hub
+2.0
12.4
-0.0
(2 places 180° apart)
REEL
FRONT VIEW
CARRIER
TAPE
USER
FEED
DIRECTION
COVER TAPE
Notes:
1. Reel shall be labeled with the following information (as a minimum).
a. manufacturers name or symbol
b. Avago Technologies part number
c. purchase order number
d. date code
1.5 min.
13.0±0.2
21.0±0.8
e. quantity of units
2. A certificate of compliance shall be issued and accompany each shipment of product.
3. Reel must not be made with or contain ozone depleting materials.
4. All dimensions in millimeters (mm).
Order Information
Part Number
No. of Devices Container
ACPM-7886-BLK 100
ACPM-7886-TR1 1000
Bulk
7" Tape and Reel
7
