Product Specification
M270DTN01.5
CN2
PIN #
Symbol
R3_0N
DESCRIPTION
1
Negative LVDS differential data input (Port3 data)
Positive LVDS differential data input (Port3 data)
Negative LVDS differential data input (Port3 data)
Positive LVDS differential data input (Port3 data)
Negative LVDS differential data input (Port3 data)
Positive LVDS differential data input (Port3 data)
Ground
2
R3_0P
R3 1N
R3 1P
R3 2N
R3 2P
GND
3
4
5
6
7
8
R3_CLKN
R3_CLKP
GND
Negative LVDS differential clock input (Port3 clock)
Positive LVDS differential clock input (Port3 clock)
Ground
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
R3 3N
R3 3P
NC
Negative LVDS differential data input (Port3 data)
Positive LVDS differential data input (Port3 data)
No connection (for AUO test only. Do not connect)
No connection (for AUO test only. Do not connect)
Ground
NC
GND
R4_0N
R4_0P
R4_1N
R4_1P
R4 2N
R4 2P
GND
Negative LVDS differential data input (Port4 data)
Positive LVDS differential data input (Port4 data)
Negative LVDS differential data input (Port4 data)
Positive LVDS differential data input (Port4 data)
Negative LVDS differential data input (Port4 data)
Positive LVDS differential data input (Port4 data)
Ground
R4 CLKP
R4 CLKP
GND
Negative LVDS differential clock input (Port4 clock)
Positive LVDS differential clock input (Port4 clock)
Ground
R4_3N
R4_3P
NC
Negative LVDS differential data input (Port4 data)
Positive LVDS differential data input (Port4 data)
No connection (for AUO test only. Do not connect)
No connection (for AUO test only. Do not connect)
Polarity SYNC (O)
NC
Polarity_SYNC
12
AUO [ AUO ]
