Data Polling Flash
When a page is being programmed into the Flash, reading an address location within
the page being programmed will give the value 0xFF. At the time the device is ready for
a new page, the programmed value will read correctly. This is used to determine when
the next page can be written. Note that the entire page is written simultaneously and any
address within the page can be used for polling. Data polling of the Flash will not work
for the value 0xFF, so when programming this value, the user will have to wait for at
least tWD_FLASH before programming the next page. As a chip-erased device contains
0xFF in all locations, programming of addresses that are meant to contain 0xFF, can be
skipped. See Table 97 for tWD_FLASH value.
Data Polling EEPROM
When a new byte has been written and is being programmed into EEPROM, reading the
address location being programmed will give the value 0xFF. At the time the device is
ready for a new byte, the programmed value will read correctly. This is used to deter-
mine when the next byte can be written. This will not work for the value 0xFF, but the
user should have the following in mind: As a chip-erased device contains 0xFF in all
locations, programming of addresses that are meant to contain 0xFF, can be skipped.
This does not apply if the EEPROM is Re-programmed without chip-erasing the device.
In this case, data polling cannot be used for the value 0xFF, and the user will have to
wait at least tWD_EEPROM before programming the next byte. See Table 97 for tWD_EEPROM
value.
Table 97. Minimum Wait Delay Before Writing the Next Flash or EEPROM Location
Symbol
Minimum Wait Delay
4.5 ms
tWD_FUSE
tWD_FLASH
tWD_EEPROM
tWD_ERASE
4.5 ms
9.0 ms
9.0 ms
Figure 113. Serial Programming Waveforms
SERIAL DATA INPUT
MSB
LSB
LSB
(MOSI)
SERIAL DATA OUTPUT
MSB
(MISO)
SERIAL CLOCK INPUT
(SCK)
SAMPLE
234
ATmega8(L)
2486M–AVR–12/03
