ATmega8(L)
changes are effective. This is particularly important if the Output Compare2 interrupt
is used to wake up the device, since the Output Compare function is disabled during
writing to OCR2 or TCNT2. If the write cycle is not finished, and the MCU enters
sleep mode before the OCR2UB bit returns to zero, the device will never receive a
Compare Match interrupt, and the MCU will not wake up.
•
If Timer/Counter2 is used to wake the device up from Power-save mode,
precautions must be taken if the user wants to re-enter one of these modes: The
interrupt logic needs one TOSC1 cycle to be reset. If the time between wake-up and
re-entering sleep mode is less than one TOSC1 cycle, the interrupt will not occur,
and the device will fail to wake up. If the user is in doubt whether the time before re-
entering Power-save or Extended Standby mode is sufficient, the following
algorithm can be used to ensure that one TOSC1 cycle has elapsed:
1. Write a value to TCCR2, TCNT2, or OCR2.
2. Wait until the corresponding Update Busy Flag in ASSR returns to zero.
3. Enter Power-save or Extended Standby mode.
•
When the asynchronous operation is selected, the 32.768 kHZ Oscillator for
Timer/Counter2 is always running, except in Power-down and Standby modes. After
a Power-up Reset or Wake-up from Power-down or Standby mode, the user should
be aware of the fact that this Oscillator might take as long as one second to
stabilize. The user is advised to wait for at least one second before using
Timer/Counter2 after Power-up or Wake-up from Power-down or Standby mode.
The contents of all Timer/Counter2 Registers must be considered lost after a wake-
up from Power-down or Standby mode due to unstable clock signal upon start-up,
no matter whether the Oscillator is in use or a clock signal is applied to the TOSC1
pin.
•
•
Description of wake up from Power-save or Extended Standby mode when the timer
is clocked asynchronously: When the interrupt condition is met, the wake up
process is started on the following cycle of the timer clock, that is, the timer is
always advanced by at least one before the processor can read the counter value.
After wake-up, the MCU is halted for four cycles, it executes the interrupt routine,
and resumes execution from the instruction following SLEEP.
Reading of the TCNT2 Register shortly after wake-up from Power-save may give an
incorrect result. Since TCNT2 is clocked on the asynchronous TOSC clock, reading
TCNT2 must be done through a register synchronized to the internal I/O clock
domain. Synchronization takes place for every rising TOSC1 edge. When waking up
from Power-save mode, and the I/O clock (clkI/O) again becomes active, TCNT2 will
read as the previous value (before entering sleep) until the next rising TOSC1 edge.
The phase of the TOSC clock after waking up from Power-save mode is essentially
unpredictable, as it depends on the wake-up time. The recommended procedure for
reading TCNT2 is thus as follows:
1. Write any value to either of the registers OCR2 or TCCR2.
2. Wait for the corresponding Update Busy Flag to be cleared.
3. Read TCNT2.
•
During asynchronous operation, the synchronization of the Interrupt Flags for the
asynchronous timer takes three processor cycles plus one timer cycle. The timer is
therefore advanced by at least one before the processor can read the timer value
causing the setting of the Interrupt Flag. The Output Compare Pin is changed on the
timer clock and is not synchronized to the processor clock.
