USART Control and Status
Register n B – UCSRnB
Bit
7
RXCIEn
R/W
0
6
TXCIEn
R/W
0
5
UDRIEn
R/W
0
4
RXENn
R/W
0
3
TXENn
R/W
0
2
UCSZn2
R/W
1
0
TXB8n
R/W
0
RXB8n
UCSRnB
Read/Write
Initial Value
R
0
0
• Bit 7 – RXCIEn: RX Complete Interrupt Enable n
Writing this bit to one enables interrupt on the RXCn Flag. A USART Receive Complete
interrupt will be generated only if the RXCIEn bit is written to one, the Global Interrupt
Flag in SREG is written to one and the RXCn bit in UCSRnA is set.
• Bit 6 – TXCIEn: TX Complete Interrupt Enable n
Writing this bit to one enables interrupt on the TXCn Flag. A USART Transmit Complete
interrupt will be generated only if the TXCIEn bit is written to one, the Global Interrupt
Flag in SREG is written to one and the TXCn bit in UCSRnA is set.
• Bit 5 – UDRIEn: USART Data Register Empty Interrupt Enable n
Writing this bit to one enables interrupt on the UDREn Flag. A Data Register Empty
interrupt will be generated only if the UDRIEn bit is written to one, the Global Interrupt
Flag in SREG is written to one and the UDREn bit in UCSRnA is set.
• Bit 4 – RXENn: Receiver Enable n
Writing this bit to one enables the USART Receiver. The Receiver will override normal
port operation for the RxDn pin when enabled. Disabling the Receiver will flush the
receive buffer invalidating the FEn, DORn, and UPEn Flags.
• Bit 3 – TXENn: Transmitter Enable n
Writing this bit to one enables the USART Transmitter. The Transmitter will override nor-
mal port operation for the TxDn pin when enabled. The disabling of the Transmitter
(writing TXENn to zero) will not become effective until ongoing and pending transmis-
sions are completed, i.e., when the Transmit Shift Register and Transmit Buffer Register
do not contain data to be transmitted. When disabled, the Transmitter will no longer
override the TxDn port.
• Bit 2 – UCSZn2: Character Size n
The UCSZn2 bits combined with the UCSZn1:0 bit in UCSRnC sets the number of data
bits (Character SiZe) in a frame the Receiver and Transmitter use.
• Bit 1 – RXB8n: Receive Data Bit 8 n
RXB8n is the ninth data bit of the received character when operating with serial frames
with nine data bits. Must be read before reading the low bits from UDRn.
• Bit 0 – TXB8n: Transmit Data Bit 8 n
TXB8n is the ninth data bit in the character to be transmitted when operating with serial
frames with nine data bits. Must be written before writing the low bits to UDRn.
