Figure 51 shows the count sequence close to TOP in various modes. When using phase
and frequency correct PWM mode the OCR1x Register is updated at BOTTOM. The
timing diagrams will be the same, but TOP should be replaced by BOTTOM, TOP-1 by
BOTTOM+1 and so on. The same renaming applies for modes that set the TOV1 flag at
BOTTOM.
Figure 51. Timer/Counter Timing Diagram, no Prescaling
clkI/O
clkTn
(clkI/O/1)
TCNTn
TOP - 1
TOP - 1
TOP
TOP
BOTTOM
TOP - 1
BOTTOM + 1
TOP - 2
(CTC and FPWM)
TCNTn
(PC and PFC PWM)
TOVn (FPWM)
and ICFn (if used
as TOP)
OCRnx
(Update at TOP)
Old OCRnx Value
New OCRnx Value
Figure 52 shows the same timing data, but with the prescaler enabled.
Figure 52. Timer/Counter Timing Diagram, with Prescaler (fclk_I/O/8)
clkI/O
clkTn
(clkI/O/8)
TCNTn
TOP - 1
TOP - 1
TOP
TOP
BOTTOM
TOP - 1
BOTTOM + 1
TOP - 2
(CTC and FPWM)
TCNTn
(PC and PFC PWM)
TOVn (FPWM)
and ICFn (if used
as TOP)
OCRnx
(Update at TOP)
Old OCRnx Value
New OCRnx Value
