TA = -40°C to 85°C, VCC = 1.8V to 5.5V (unless otherwise noted) (Continued)
Symbol
Parameter
Condition
Min.
Typ.
Max.
0.44
2.5
Units
mA
mA
mA
mA
mA
mA
Active 1 MHz, VCC = 2V
Active 4 MHz, VCC = 3V
Active 8 MHz, VCC = 5V
Idle 1 MHz, VCC = 2V
Idle 4 MHz, VCC = 3V
Idle 8 MHz, VCC = 5V
9.5
Power Supply Current(5)
0.2
0.8
3.3
ICC
32 kHz TOSC enabled,
VCC = 1.8V
0.55
0.8
1.6
2.6
µA
µA
Power-save mode(6)
Power-down mode(6)
32 kHz TOSC enabled,
VCC = 3V
WDT enabled, VCC = 3V
WDT disabled, VCC = 3V
6
10
2
µA
µA
0.2
VCC = 5V
Analog Comparator
Input Offset Voltage
VACIO
IACLK
tACPD
<10
40
50
mV
nA
ns
Vin = VCC/2
Analog Comparator
Input Leakage Current
VCC = 5V
Vin = VCC/2
-50
Analog Comparator
Propagation Delay
VCC = 2.7V
VCC = 4.0V
750
500
Note:
1. “Max” means the highest value where the pin is guaranteed to be read as low
2. “Min” means the lowest value where the pin is guaranteed to be read as high
3. Although each I/O port can sink more than the test conditions (20 mA at VCC = 5V, 10 mA at VCC = 3V for Port B and 10 mA
at VCC = 5V, 5 mA at VCC = 3V for all other ports) under steady state conditions (non-transient), the following must be
observed:
TQFP and QFN/MLF Package:
1] The sum of all IOL, for all ports, should not exceed 400 mA.
2] The sum of all IOL, for ports A0 - A7, C4 - C7, G2 should not exceed 100 mA.
3] The sum of all IOL, for ports B0 - B7, E0 - E7, G3 - G5 should not exceed 100 mA.
4] The sum of all IOL, for ports D0 - D7, C0 - C3, G0 - G1 should not exceed 100 mA.
5] The sum of all IOL, for ports F0 - F7, should not exceed 100 mA.
If IOL exceeds the test condition, VOL may exceed the related specification. Pins are not guaranteed to sink current greater
than the listed test condition.
4. Although each I/O port can source more than the test conditions (20 mA at VCC = 5V, 10 mA at VCC = 3V for Port B and 10mA
at VCC = 5V, 5 mA at VCC = 3V for all other ports) under steady state conditions (non-transient), the following must be
observed:
TQFP and QFN/MLF Package:
1] The sum of all IOH, for all ports, should not exceed 400 mA.
2] The sum of all IOH, for ports A0 - A7, C4 - C7, G2 should not exceed 100 mA.
3] The sum of all IOH, for ports B0 - B7, E0 - E7, G3 - G5 should not exceed 100 mA.
4] The sum of all IOH, for ports D0 - D7, C0 - C3, G0 - G1 should not exceed 100 mA.
5] The sum of all IOH, for ports F0 - F7, should not exceed 100 mA.
If IOH exceeds the test condition, VOH may exceed the related specification. Pins are not guaranteed to source current
greater than the listed test condition.
5. All bits set in the “Power Reduction Register” on page 34.
6. Typical values at 25 °C. Maximum values are characterized values and not test limits in production.
