DC Characteristics
Symbol Parameter
Condition
Min
Typ
Max
Units
ILI
Input Load Current VIN = -0.1V to VCC + 1V
10
µA
Output Leakage
VOUT = -0.1V to VCC + 0.1V
Current
ILO
10
90
µA
VCC = Max,
Com.
Ind.
65
70
mA
VIN = Max,
Outputs Open
Power Supply
Current, Standby
ICC
C-15
100
mA
mA
Output Short
Circuit Current
(1)(2)
IOS
VOUT = 0.5V
-120
VIL
VIH
Input Low Voltage
Input High Voltage
3.0 ≤ VCC ≤ 3.6V
-0.6
2.0
0.8
VCC + 0.75
0.5
V
V
V
V
V
I
I
I
OL = 16 mA
OL = 12 mA
OL = 24 mA
Com., Ind.
Mil.
Output Low
Voltage
VIN = VIH or VIL,
VCC = Min
VOL
0.5
Com.
0.8
Output High
Voltage
VIN = VIH or VIL,
VCC = Min
VOH
IOH = -2.0 mA
2.4
V
Notes: 1. Not more than one output at a time should be shorted. Duration of short circuit test should not exceed 30 sec.
2. This test is performed at initial characterisation only.
Input Test Waveforms and
Measurement Levels
Output Test Load
VCC
316 Ω
348 Ω
tR, tF < 3 ns (10% to 90%)
ATF750LVC
4
