AT85C51SND3Bx
Assembly code: mov #, direct
NFCLK / 2
NFCEx
NFCLE
NFALE
NFWE
NFRE
NFD[7:0]
Read data, TRS cleared
CPU: 40 ns setup, timing [1.5; 0.5]
[15;30] ns hold
NFCEx
NFCLE
NFALE
NFWE
NFRE
NFD[7:0]
Read data, TRS set
CPU: 40 ns setup Timing [1; 1]
[15;30] ns hold
•
A read of NFDAT returns to the CPU the byte contained in that register, but does not
launch an extra background “read cycle”.
Assembly code: mov #, direct
In all the previous examples, the NFCE line is asserted low and de-asserted at the end
of the cycle. This allows minimizing the power consumption.
Access Example
Figure 80 shows a read access in a 512B page. Note that the NFCE must be held low
during the access time for that kind of memory:
