AX88179
USB 3.0 to 10/100/1000M Gigabit Ethernet Controller
eFuse
OFFSET
00h
HIGH BYTE
LOW BYTE
Node ID 1
Node ID 3
Node ID 0 (Note_1)
Node ID 2
01h
02h
Node ID 5
Node ID 4
03h
PID_HB
PID_LB
04h
VID_HB
VID_LB
05h
Reserved
Max. Power for Bus Power
EndPoint1 for FS
06h
EndPoint1 for SS/HS
Language ID High Byte
Length of Product String (bytes)
Length of Manufacturer String (bytes)
Length of BOS-type Descriptor (bytes)
07h
Language ID Low Byte
Offset of Product String (0Bh)
Offset of Manufacturer String (11h)
Offset of BOS-type Descriptor (16h)
08h
09h
0Ah
10~0Bh
15~11h
16h
Product String: (Max.) 12 bytes
Manufacturer String: (Max.) 10 bytes
BOS-type Descriptor: (Max.) 2 bytes,
LowByte: SS USB Device Capability bU1DevExitLat,
HighByte: SS USB Device Capability bU2DevExitLat LowByte
17h
Max. Burst, [7:4] for EP3, [3:0] for EP2
BOS-type Descriptor: 1 byte,
SS USB Device Capability bU2DevExitLat HighByte
18h
19h
Flag
Reserved
LED_Mode_LB
eFuse Checksum[7:0] (Note_2)
LED_Mode_HB
1Ah
Fixed_pattern (First byte)
1E~1Bh
1Fh
Fixed_pattern (9th~2nd bytes)
Max. Power for Self Power [3:0] and
Reserved [7:4]
Fixed_pattern (10th byte)
Table 5
: eFuse (64-byte) Memory Map
Note_1: The Node ID 0 value cannot be set to 0xFF and 1st bit of Node ID 0 can not be set to “1” (i.e. cannot be set to
multicast MAC address).
Note_2: The correct value of eFuse Checksum field must be equal to (0xFF - SUM [eFuse offset 00h ~ 1Fh excluding eFuse
Checksum field]). If SUM [eFuse offset 00h ~ 1Fh excluding eFuse Checksum field] has carry, please add ‘1’ to its
result.
18
