AOZ1284
Functional Block
Absolute Maximum Ratings
Recommended Operating Ratings
Exceeding the Absolute Maximum Ratings may damage the
device.
This device is not guaranteed to operate beyond the
Recommended Operating Ratings.
Parameter
Supply Voltage (VIN)
LX to GND
EN, SS, FB and COMP to GND
BST to GND
Junction Temperature (TJ)
Storage Temperature (TS)
ESD Rating HB Model(1)
Rating
40V
-0.7V to VIN+0.3V
-0.3V to +6V
-0.3V to VLX+6V
+150°C
Parameter
Supply Voltage (VIN)
Output Voltage (VOUT
Ambient Temperature (TA)
Package Thermal Resistance
EPAD SO-8 (JA)
Rating
3.0V to 36V
0.8V to VIN*0.85V
-40°C to +85°C
)
50°C/W
-65°C to +150°C
2kV
Note:
1. Devices are inherently ESD sensitive, handling precautions are
required. Human body model rating: 1.5kΩ in series with 100pF.
