LJ T Fail Safe 88-5388/91-5388
(MS27661)
lanyard release plug
+.003
–.002
.594
+.007
–.003
.575
SOCKET INSERT
.275 MAX.
OUTER SLEEVE
MOVEMENT
DURING MATING
+.012
–.003
PIN INSERT
.019
V
D
B
LANYARD
PULLED TAUT
AGAINST A
.500
DIA. MANDREL
L
A
±.031
MS LANYARD LENGTH
6.250STD.
FOR PROPRIETARY LANYARD LENGTH
SEE LANYARD LENGTH TABLE
*
To complete order number see page 40-41.
A
Dia.
Max.
D Max.
Accessory
Dia.
V Thread
UNEF
Class 2A (Plated)
Shell
Size
B
Max.
L
Max.
1.703
1.703
1.703
1.703
1.703
1.703
1.703
1.766
11
13
15
17
19
21
23
25
1.393
1.558
1.669
1.797
1.926
2.054
2.183
2.293
1.797
1.969
2.078
2.203
2.323
2.469
2.594
2.703
.740
.926
.5625-24
.6875-24
1.051
1.176
1.300
1.426
1.551
1.676
.8125-20
.9375-20
1.0625-18
1.1875-18
1.3125-18
1.4375-18
All dimensions for reference only.
39
