LJ T00 (MS27469) — hermetic
wall mounting receptacle
±.005
1.047
±.005
S
.741
+.010
–.000
R
(TP)
±.025
.258
.659
R
(TP)
N
S
RR
T
(4 HOLES)
*
LJ T0 0 H-XX-XXX
** LJ T0 0 Y-XX-XXX (MS 2 7 4 6 9 YXXD)
*** LJ TS 0 0 Y-XX-XXX (MS 2 7 4 6 9 YXXE)
.005 DIA
M
*
To complete order number see page 53.
** Interfacial seal wafer; to complete order number see page 53.
*** High temperature version, interfacial seal wafer with stainless steel shell;
to complete order number see page 53.
N Dia.
+.001
–.005
T
Dia.
±.005
RR
Thread
Class 2A
Shell
Size
R
(TP)
S
±.016
9
11
13
15
17
19
21
23
25
.572
.700
.719
.812
.938
1.031
1.125
1.219
1.312
1.438
1.562
1.688
1.812
.128
.128
.128
.128
.128
.128
.128
.147
.147
.6875-24 UNEF
.8125-20 UNEF
.9375-20 UNEF
1.0625-18 UNEF
1.1875-18 UNEF
1.3125-18 UNEF
1.4375-18 UNEF
1.5625-18 UNEF
1.6875-18 UNEF
.850
.906
.975
.969
1.100
1.207
1.332
1.457
1.582
1.062
1.156
1.250
1.375
1.500
All dimensions for reference only.
35
AMPHENOL [ Amphenol ]
