LJ T01R — crimp
line receptacle
C
S
1.219 MAX
+.006
–.000
.717
M
D
S
N
V
1.656 MAX
±.031
.918
*
*
LJ T0 1 RE-XX-XXX
LJ T0 1 RT-XX-XXX
VIEW D ENLARGED
FOR COAXIAL USE ONLY
*
To complete order number see page 53.
M
N
+.001
–.005
V Thread Ref.
Class 2A
(Plated)
Shell
Size
C
Max.
+.000
–.005
S
±.016
9
11
13
15
17
19
21
23
25
1.094
1.188
1.281
1.375
1.469
1.594
1.719
1.844
1.969
.632
.632
.632
.632
.632
.632
.602
.602
.602
.572
.700
.938
1.031
1.125
1.219
1.312
1.438
1.562
1.688
1.812
.4375-28 UNEF
.5625-24 UNEF
.6875-24 UNEF
.8125-20 UNEF
.9375-20 UNEF
1.0625-18 UNEF
1.1875-18 UNEF
1.3125-18 UNEF
1.4375-18 UNEF
.850
.975
1.100
1.207
1.332
1.457
1.582
All dimensions for reference only.
