JT/LJ T — acce s s orie s
strain relief (crimp type)
L
B
G
BB
Y
GROMMET
*
1 0 -4 0 5 9 8 2 -XXX (MS 2 7 5 0 6 XXX-2 re fe re n c e M8 5 0 4 9 /4 9 )
For MS stamping identification, accessories must be ordered by MS part number.
If ordered by 10-part number, they will be stamped with said number.
*To complete order number, add shell size and suffix number.
10-Number
Suffix
MS27506
Suffix
M85049/49
Suffix
Finish
Chromate treat
-XX0
-XX5
-XX7
-XX9
-XXG
NA
Anodic coating
CXX-2
AXX-2
BXX-2
FXX-2
(-2-XXA)
NA
Cadmium plate nickel base
Olive drab, cadmium, nickel base
Electroless nickel
(-2-XXW)
(-2-XXN)
For example: Shell size 10 with cadmium plate, nickel base would be 10-405982-107
or M85049/49-2-10W
Y
B
Thread (Modified)
BB
Dia.
Dia.
Shell
Size
+.010
–.025
G
Max.
L
Max.
Size
Class 2B
Modified
Minor Dia.
+.000
–.011
Screw
Size
8
10
12
14
16
18
20
22
24
.125
.188
.312
.375
.500
.625
.625
.750
.800
.775
.837
.984
.984
.4375-28UNEF
.5625-24UNEF
.6875-24UNEF
.8125-20UNEF
.9375-20UNEF
1.0625-18UNEF
1.1875-18UNEF
1.3125-18UNEF
1.4375-18UNEF
.399 – .405
.524 – .529
.649 – .654
.766 – .771
.891 – .896
1.002 – 1.007
1.135 – 1.140
1.252 – 1.257
1.377 – 1.382
.250
.312
.438
.562
.625
.750
.750
.938
1.000
6-32UNC
6-32UNC
6-32UNC
6-32UNC
6-32UNC
8-32UNC
8-32UNC
8-32UNC
8-32UNC
.963
.984
1.087
1.150
1.400
1.400
1.587
1.681
1.234
1.234
1.234
1.234
1.359
1.281
All dimensions for reference only.
Note: For solder type cable clamp 10-241055-XXX (M85049/49) consult Amphenol, Sidney, NY.
28
