Cables and Nano-Miniature Capabilities
Amphenol
Aerospace
Experience
With over 40 years experience and multiple locations in North
America and Asia, Amphenol Aerospace has diverse
capabilities to design and manufacture harsh environment cable
assemblies. Our engineers can design cables and harnesses to
fit a wide variety of requirements.
From simple point-point assemblies to ruggedized overmolded
harnesses, Amphenol has the capabilities to meet a diverse
range of cable needs.
Production
Amphenol's Caꢈle Production
Production Capabilities Include:
• Automated Twisters, strippers,
cutters, crimpers, braider
• Primary wire extrusion/jacketing
• Custom overmold presses with
in-house production tooling
• High Speed twisted shielded pair
RF capabilities
• Full testing capabilities for DWV,
IR, Continuity, etc.
braider
Nano-Circular & Nano-Rectangular Circular Micro-D
Amphenol’s Nano-Circular and Nano-Rectangular Series
of connectors offer a contact spacing of 0.025 in pitch.
This means you get even a greater density of connections
in a smaller package. It will allow you to fit up to 4 times
the connectors when in comparison to the standard
Micro-D (0.050 in pitch) with the same amount of contacts.
Amphenol’s Nano Series also offers up to 70% weight
savings over the standard Micro-D, making a clear choice
for those tight-fitting applications.
Amphenol’s New Circular Micro-D Series allows the same
contact pitch of .050 in spacing while utilizing a push /pull
coupling mechanism that has less than a 2 lb. mate and
unmate force. Designed for tight-fitting rugged
environments, the Circular Micro-D features an
aluminum shell and insert sizes down to a size 5.
• 3A per contact
• .050 in spacing
• Shell Size’s 5 and up!
• 1A per contact
• .025 in spacing
Please contact Amphenol for more information.
• Rugged and Lightweight
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
