* Note : 1. All inputs can be don’t care when
is high at the CLK high going edge.
CS
2. Bank active & read/write are controlled by BA.
BA
0
Active & Read/Write
Bank A
1
Bank B
3. Enable and disable auto precharge function are controlled by A10/AP in read/write command.
A10/AP
BA
0
Operation
Disable auto precharge, leave bank A active at end of burst.
Disable auto precharge, leave bank B active at end of burst.
Enable auto precharge, precharge bank A at end of burst.
Enable auto precharge, precharge bank B at end of burst.
0
1
0
1
1
4. A10/AP and BA control bank precharge when precharge command is asserted.
A10/AP
BA
0
Precharge
Bank A
0
0
1
1
Bank B
X
Both Bank
