12. About Burst Type Control
At MRS A3=”0”. See the BURST SEQUENCE TABE.(BL=4,8)
BL=1,2,4,8 and full page wrap around.
At MRS A3=” 1”. See the BURST SEQUENCE TABE.(BL=4,8)
BL=4,8 At BL=1,2 Interleave Counting = Sequential Counting
Sequential counting
Basic
MODE
Interleave counting
Every cycle Read/Write Command with random column address can realize
Random Column Access.
That is similar to Extended Data Out (EDO) Operation of convention DRAM.
Random
MODE
Random column Access
tCCD = 1 CLK
13. About Burst Length Control
At MRS A2,1,0 = “000”.
At auto precharge, tRAS should not be violated.
1
Basic
MODE
At MRS A2,1,0 = “001”.
At auto precharge, tRAS should not be violated.
At MRS A2,1,0 = “010”
2
4
8
At MRS A2,1,0 = “011”.
At MRS A9=”1”.
Read burst = 1,2,4,8, full page/write Burst =1
At auto precharge of write, tRAS should not be violated.
Before the end of burst, Row precharge command of the same bank
Stops read/write burst with Row precharge.
Special
BRSW
MODE
Interrupt
RAS
(Interrupted by Precharge)
tRDL= 2 with DQM, valid DQ after burst stop is 1,2 for CL=2,3 respectively
Interrupt
MODE
During read/write burst with auto precharge,
Before the end of burst, new read/write stops read/write burst and starts new
read/write burst or block write.
interrupt cannot be issued.
RAS
Interrupt
CAS
During read/write burst with auto precharge,
interrupt can not be issued.
CAS
