ORDERING INFORMATION
Industrial Products
AMD programmable logic products for industrial applications are available with several ordering options.The order number (Valid
Combination) is formed by a combination of:
MACH 211
SP -10
J
I
FAMILY TYPE
OPTIONAL PROCESSING
MACH = Macro Array CMOS High-Speed
Blank = Standard Processing
DEVICE NUMBER
OPERATING CONDITIONS
211 = 64 Macrocells, 44 Pins,
Power-Down mode,
I = Industrial (–40°C to +85°C)
Bus-Friendly Inputs and I/Os
PACKAGE TYPE
J = 44-Pin Plastic Leaded Chip
Carrier (PL 044)
PRODUCT DESIGNATION
SP = In-system Programmable
SPEED
-10 = 10 ns t
-12 = 12 ns t
PD
PD
-14 = 14.5 ns t
PD
-18 = 18 ns t
-24 = 24 ns t
PD
PD
Valid Combinations
Valid Combinations
MACH211SP-10
The Valid Combinations table lists configurations planned to
be supported in volume for this device. Consult the local AMD
sales office to confirm availability of specific valid combina-
tions and to check on newly released combinations.
MACH211SP-12
MACH211SP-14
MACH211SP-18
MACH211SP-24
JI
6
MACH211SP-10/12/14/18/24 (Ind)
