Introduction
MAX II devices have an internal linear voltage regulator which supports
external supply voltages of 3.3 V or 2.5 V, regulating the supply down to
the internal operating voltage of 1.8 V. MAX IIG devices only accept 1.8 V
as an external supply voltage. Except for external supply voltage
requirements, MAX II and MAX II G devices have identical pin-outs and
timing specifications.
Table 1–5
shows the external supply voltages
supported by the MAX II family.
Table 1–5. MAX II External Supply Voltages
EPM240
EPM570
EPM1270
EPM2210
3.3 V, 2.5 V
Devices
EPM240G
EPM570G
EPM1270G
EPM2210G
(1)
1.8 V
MultiVolt core external
supply voltage (V
CCINT
)
(2)
MultiVolt I/O interface
voltage levels (V
CCIO
)
Notes to
Table 1–5:
(1)
(2)
1.5 V, 1.8 V, 2.5 V, 3.3 V
1.5 V, 1.8 V, 2.5 V, 3.3 V
MAX IIG devices do not have an internal voltage regulator and only accept 1.8 V
on their
VCCINT
pins. Contact Altera for availability on these devices.
MAX II devices operate internally at 1.8 V.
