A1180/81/82/83
Sensitive Two-Wire Field-Programmable Chopper-Stabilized Unipolar Hall Effect Switches
THERMAL CHARACTERISTICS may require derating at maximum conditions, see application information
Characteristic
Symbol
Test Conditions*
Value Units
Package LH, 1-layer PCB with copper limited to solder pads
228 ºC/W
Package LH, 2-layer PCB with 0.463 in.2 of copper area each side
connected by thermal vias
RθJA
Package Thermal Resistance
110
ºC/W
Package UA, 1-layer PCB with copper limited to solder pads
165 ºC/W
*Additional thermal information available on Allegro Web site.
Power Derating Curve
25
24
23
V
CC(max)
22
21
20
19
18
17
16
15
14
13
12
11
10
9
2-layer PCB, Package LH
(RθJA = 110 ºC/W)
1-layer PCB, Package UA
(RθJA = 165 ºC/W)
8
7
1-layer PCB, Package LH
(RθJA = 228 ºC/W)
6
5
4
V
CC(min)
3
2
20
40
60
80
100
120
140
160
180
Temperature (ºC)
Power Dissipation versus Ambient Temperature
1900
1800
1700
1600
1500
1400
1300
1200
1100
1000
900
800
700
600
500
400
300
200
100
0
20
40
60
80
100
120
140
160
180
Temperature (°C)
