[AK4679]
Parameter
min
typ
max
Unit
Power Supply Current:
Power Up (PDNE and PDNA pin = “H”, All Circuits Power-up)
AVDD + DVDD + PVDD +
TVDDA +TVDDE
(Note 32)
(Note 33)
(Note 32)
(Note 33)
(Note 36)
-
-
-
-
6.2
9.6
3.5
4.2
3.1
-
14.4
-
mA
mA
mA
mA
mA
SVDD (No Load)
6.3
VDDE
Power Down (PDNA pin = PDNE pin = “L”) (Note 34)
AVDD + PVDD + DVDD + TVDDA
+TVDDE+ SVDD
-
-
1
10
μA
SVDD (Note 35)
VDDE
0
2.4
10
8
μA
μA
Note 32. EXT Slave Mode, fs=44.1kHz, No input, No load, PMADL = PMADR = PMDAL = PMDAR = PMPFIL =
PMEQ = PMDRC = PMLO = PMRO = PMHPL = PMHPR = PMSPK = PMRCV = PMVCM bits = “1”, PMPLL
= PMMP1 = PMMP2 = M/S = PMOSC = PMMIX = PMSRAI = PMSRAO = PMSRBI = PMSRBO = PMPCMA
= PMPCMB bits = “0”.
AVDD= 3.9mA (typ), DVDD= 1.4mA (typ), PVDD= 0.75mA (typ), SVDD=3.5mA (typ), TVDD = 0.1mA
(typ).
Note 33. PLL Master Mode, Audio I/F sampling frequency =44.1kHz, PCM I/F A sampling frequency =16kHz, PCM I/F
B sampling frequency = 8kHz, No input, No load, PMADL = PMADR = PMDAL = PMDAR = PMPFIL =
PMEQ = PMDRC = PMLO = PMRO = PMHPL = PMHPR = PMSPK = PMRCV = PMVCM = PMPLL =
PMMP1 = PMMP2 = M/S = PMOSC = PMMIX = PMSRAI = PMSRAO = PMSRBI = PMSRBO = PMPCMA
= PMPCMB bits = “1”. PLL Reference Clock = MCKI = 11.2896MHz. In this case, output current of the
MPWR1 and MPWR2 pins are 0mA.
AVDD= 4.6mA (typ), DVDD= 4.0mA (typ), PVDD= 0.78mA (typ), SVDD=4.2mA (typ), TVDD = 0.2mA (typ)
Note 34. All digital input pins are fixed to each supply pin TVDDA, TVDDE or VSS2, VSS4.
Note 35. AVDD, DVDD, PVDD, TVDDA, VDDE and TVDDE are powered OFF.
Note 36. fs=8 kHz 16 bit (FSD bits=0h, LAW bits = 0h, DIFD bit = 3h, TESTC bits = 1h, DSP running with programmed
connecting DIN1 with DOUT2 and DIN2 with DOUT1.
■ Power Consumption for Each Operation Mode
Condition: Ta=25°C; AVDD=DVDD=PVDD=TVDD =1.8V, SVDD=4.2V; VDEE=1.2V,
VSS1=VSS2=VSS3=VSS4=VSS5=0V; fs=44.1kHz; fs2=16kHz, fs3=8kHz, External Slave Mode,
BICK=64fs; No data input, Receiver / Speaker / Headphone = No Load.
AVDD
[mA]
1.93
1.27
0.82
DVDD+PVDD
[mA]
TVDD
[mA]
SVDD
[mA]
0.003
0.9
0.003
1.3
Total Power
Mode
[mW]
5.0
6.9
3.7
8.5
9.4
LIN1/RIN1 Æ ADC (Note 37)
DAC Æ Lineout (Note 38)
DAC Æ HP (Note 39)
DAC Æ RCV (Note 40)
DAC Æ SPK (Note 41)
0.74
0.46
1.21
0.44
0.44
0.1
0.02
0.02
0.02
0.02
1.22
1.75
1.35
PCM I/F A Æ PCM I/F B &
PCM I/F B Æ PCM I/F A (Note 42)
0.21
1.19
0.1
0.003
2.7
Note 37. PMVCM = PMADL = PMADR bits = “1” , PFSDO bit = “0”
Note 38. PMVCM = PMDAL = PMDAR = PMLO = PMRO bits = “1” , DASEL1-0 bits = “10”
Note 39. PMVCM = PMDAL = PMDAR = PMHPL = PMHPR bits = “1” , DASEL1-0 bits = “10”
Note 40. PMVCM = PMDAL = PMDAR = PMRCV bits = “1” , DASEL1-0 bits = “10”
Note 41. PMVCM = PMDAL = PMDAR = PMSPK bits = “1” , DASEL1-0 bits = “10”
Note 42. PMVCM = PMOSC = PMPCMA = PMSRAI = PMSRAO = PMPCMB = PMSRBI = PMSRBO bits = “1”
Table 1. Power Consumption for Each Operation Mode (typ)
MS1402-E-06
2013/02
- 18 -
