ASAHI KASEI
[AK4367]
Parameter
Symbol
min
typ
max
Units
Control Interface Timing (I2C Bus mode): (Note 22)
SCL Clock Frequency
fSCL
tBUF
-
4.7
4.0
4.7
4.0
4.7
-
0.25
-
-
-
-
-
-
-
-
100
-
-
-
-
-
-
-
kHz
µs
µs
µs
µs
µs
µs
µs
µs
µs
µs
ns
Bus Free Time Between Transmissions
Start Condition Hold Time (prior to first clock pulse)
Clock Low Time
Clock High Time
Setup Time for Repeated Start Condition
SDA Hold Time from SCL Falling
SDA Setup Time from SCL Rising
Rise Time of Both SDA and SCL Lines
Fall Time of Both SDA and SCL Lines
Setup Time for Stop Condition
tHD:STA
tLOW
tHIGH
tSU:STA
tHD:DAT
tSU:DAT
tR
(Note 23)
-
-
-
-
-
1.0
0.3
-
tF
tSU:STO
tSP
4.0
0
Pulse Width of Spike Noise Suppressed by Input Filter
50
Power-down & Reset Timing
PDN Pulse Width
(Note 24)
tPD
150
-
-
ns
Note 22. I2C is a registered trademark of Philips Semiconductors.
Note 23. Data must be held long enough to bridge the 300ns-transition time of SCL.
Note 24. The AK4367 can be reset by bringing PDN pin = “L” to “H” only upon power up.
Purchase of Asahi Kasei Microsystems Co., Ltd I2C components conveys a license under the Philips
I2C patent to use the components in the I2C system, provided the system conform to the I2C
specifications defined by Philips.
MS0247-E-02
2005/10
- 10 -
