Low Noise, Cascadable
Silicon Bipolar MMIC Amplifier
Technical Data
INA-02184
INA-02186
Circuit (MMIC) feedback amplifi-
Features
Package 84
ers housed in low cost plastic
packages. They are designed for
narrow or wide bandwidth
commercial applications that
require high gain and low noise IF
or RF amplification.
• Cascadable 50 Ω Gain Block
• Low Noise Figure:
2.0 dB Typical at 0.5 GHz
• High Gain:
31 dB Typical at 0.5 GHz
26 dB Typical at 1.5 GHz
The INA series of MMICs is
fabricated using HP’s 10 GHz f ,
• 3 dB Bandwidth:
T
DC to 0.8 GHz
25 GHz f
, ISOSAT™-I silicon
MAX
• Unconditionally Stable
(k>1)
bipolar process which uses nitride
self-alignment, submicrometer
lithography, trench isolation, ion
implantation, gold metallization
and polyimide intermetal dielec-
tric and scratch protection to
achieve excellent performance,
uniformity and reliability.
Package 86
• Low Cost Plastic Package
Description
TheINA-02184andINA-02186are
low-noise silicon bipolar Mono-
lithic Microwave Integrated
Typical Biasing Configuration
VCC
RFC (Optional)
R
bias
4
C
C
block
block
3
RF IN
RF OUT
1
V
= 5.5 V
d
2
5965-9675E
6-96
