Moisture Proof Packaging
Baking Conditions
All HSDL-3612 options are shipped in moisture proof package. Once
opened, moisture absorption begins.
If the parts are not stored in dry
conditions, they must be baked
before reflow to prevent damage
to the parts.
Package
In reels
In bulk
Temp.
60°C
Time
UNITS IN A SEALED
MOISTURE-PROOF
PACKAGE
≥ 48 hours
≥ 4 hours
≥ 2 hours
≥ 1 hour
100°C
125°C
150°C
PACKAGE IS
OPENED (UNSEALED)
Baking should be done only once.
Recommended Storage Conditions
Storage
Temperature
10°C to 30°C
ENVIRONMENT
LESS THAN 30°C,
AND LESS THAN
60% RH
Relative
Humidity
below 60% RH
YES
PACKAGE IS
OPENED LESS
THAN 72 HOURS
NO BAKING
IS NECESSARY
YES
Time from Unsealing to Soldering
After removal from the bag, the
parts should be soldered within
three days if stored at the recom-
mended storage conditions. If
times longer than 72 hours are
needed, the parts must be stored
in a dry box.
NO
PERFORM RECOMMENDED
BAKING CONDITIONS
NO
13
