AD5940
Data Sheet
Bits
[11:8]
Bit Name
NMUXCON
Settings
Description
Control of N switch mux.
Reset Access
0xF
R/W
0000 NL closed, remaining switches open.
0001 N1 closed, remaining switches open.
0010 N2 closed, remaining switches open.
0011 N3 closed, remaining switches open.
0100 N4 closed, remaining switches open.
0101 N5 closed, remaining switches open.
0110 N6 closed, remaining switches open.
0111 N7 closed, remaining switches open.
1000 Reserved.
1001 N9 closed, remaining switches open.
1010 NR1 closed, remaining switches open.
1011 to 1110 NL2 closed, remaining switches open.
1111 All switches open.
[7:4]
PMUXCON
Control of Px/Pxx switch mux.
0xF
R/W
0000 PL closed, remaining switches open.
0001 PR0 closed, remaining switches open.
0010 P2 closed, remaining switches open.
0011 P3 closed, remaining switches open.
0100 P4 closed, remaining switches open.
0101 P5 closed, remaining switches open.
0110 P6 closed, remaining switches open.
0111 P7 closed, remaining switches open.
1000 P8 closed, remaining switches open.
1001 P9 closed, remaining switches open.
1010 Reserved.
1011 P11 closed, remaining switches open.
1100 Reserved.
1101 to 1110 PL2 closed, remaining switches open.
1111 All switches open.
[3:0]
DMUXCON
Control of Dx/DR0 switch mux.
0xF
R/W
0000 All switches open.
0001 DR0 closed, remaining switches open.
0010 D2 closed, remaining switches open.
0011 D3 closed, remaining switches open.
0100 D4 closed, remaining switches open.
0101 D5 closed, remaining switches open.
0110 D6 closed, remaining switches open.
0111 D7 closed, remaining switches open.
1000 D8 closed, remaining switches open.
1001 All switches closed.
1010 to 1111 All switches open.
Rev. 0 | Page 72 of 130
