27.3 8S2 – EIAJ SOIC
C
1
E
E1
L
End View
N
Top View
q
e
b
A
A1
COMMON DIMENSIONS
(Unit of Measure = mm)
SYMBOL
MIN
1.70
0.05
0.35
0.15
5.13
5.18
7.70
0.51
0˚
NOM
MAX
2.16
0.25
0.48
0.35
5.35
5.40
8.26
0.85
8˚
NOTE
A
D
A1
b
Side View
4
4
C
D
E1
E
Notes: 1. This drawing is for general information only; refer to
EIAJ Drawing EDR-7320 for additional information.
2. Mismatch of the upper and lower dies and resin burrs
are not included.
2
3. Determines the true geometric position.
4. Values b,C apply to plated terminal. The standard
thickness of the plating layer shall measure between
0.007 to .021mm.
L
q
3
e
1.27 BSC
4/15/08
TITLE
GPC
DRAWING NO.
REV.
8S2, 8-lead, 0.208” Body, Plastic Small
Outline Package (EIAJ)
Package Drawing Contact:
contact@adestotech.com
STN
8S2
F
50
AT45DB081D
3596O–DFLASH–1/2013
