AT45DB081D
26. Ordering Information
26.1 Ordering Code Detail
A T 4 5 D B 0 8 1 D – S S U
Designator
Product Family
Device Grade
U = Matte Sn lead finish, industrial
temperature range (-40°C to +85°C)
Device Density
Package Option
M
= 8-pad, 6 x 5 x 1mm MLF (VDFN)
8 = 8-megabit
SS = 8-lead, 0.150" wide SOIC
= 8-lead, 0.209" wide SOIC
S
Interface
1 = Serial
Device Revision
26.2 Green Package Options (Pb/Halide-free/RoHS Compliant)
Ordering Code(1)(2)
Package
Lead Finish
Operating Voltage
fSCK (MHz)
Operation Range
AT45DB081D-MU
AT45DB081D-MU-SL954(3)
AT45DB081D-MU-SL955(4)
8M1-A
AT45DB081D-SSU
AT45DB081D-SSU-SL954(3)
AT45DB081D-SSU-SL955(4)
8S1
8S2
Matte Sn
2.7V to 3.6V
66
Industrial
AT45DB081D-SU
(-40C to 85C)
AT45DB081D-SU-SL954(3)
AT45DB081D-SU-SL955(4)
AT45DB081D-MU-2.5
AT45DB081D-SSU-2.5
AT45DB081D-SU-2.5
8M1-A
8S1
Matte Sn
2.5V to 3.6V
50
8S2
Notes: 1. The shipping carrier option is not marked on the devices.
2. Standard parts are shipped with the page size set to 264-bytes. The user is able to configure these parts to a 256-byte page
size if desired.
3. Parts ordered with suffix SL954 are shipped in bulk with the page size set to 256-bytes. Parts will have a 954 or SL954
marked on them.
4. Parts ordered with suffix SL955 are shipped in tape and reel with the page size set to 256-bytes. Parts will have a 954 or
SL954 marked on them.
Package Type
8M1-A
8S1
8-pad, 6 x 5 x 1.00mm Body, Very Thin Dual Flat Package No Lead MLF™ (VDFN)
8-lead, 0.150” Wide, Plastic Gull Wing Small Outline Package (JEDEC SOIC)
8-lead, 0.209” Wide, Plastic Gull Wing Small Outline Package (EIAJ SOIC)
8S2
47
3596O–DFLASH–1/2013
