AD724
ABSOLUTE MAXIMUM RATINGS*
PIN CONFIGURATION
16-Lead Wide Body (SOIC)
(R-16)
Supply Voltage, APOS to AGND . . . . . . . . . . . . . . . . . . +6 V
Supply Voltage, DPOS to DGND . . . . . . . . . . . . . . . . . . +6 V
AGND to DGND . . . . . . . . . . . . . . . . . . . . . –0.3 V to +0.3 V
Inputs . . . . . . . . . . . . . . . . . DGND – 0.3 V to DPOS + 0.3 V
Internal Power Dissipation . . . . . . . . . . . . . . . . . . . . . . 800 mW
Operating Temperature Range . . . . . . . . . . . . . 0°C to +70°C
Storage Temperature Range . . . . . . . . . . . . . –65°C to +125°C
Lead Temperature Range (Soldering 30 sec) . . . . . . . . +230°C
1
2
3
4
5
6
7
8
16
HSYNC
STND
AGND
FIN
15 VSYNC
14
13
12
11
10
9
DPOS
DGND
SELECT
LUMA
COMP
CRMA
AD724
TOP VIEW
(Not to Scale)
APOS
ENCD
RIN
*Stresses above those listed under Absolute Maximum Ratings may cause perma-
nent damage to the device. This is a stress rating only; functional operation of the
device at these or any other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device reliability.
GIN
BIN
Thermal Characteristics: 16-Lead SOIC Package: θJA = 100°C/W.
ORDERING GUIDE
Temperature Package
Package
Option
Model
Range
Description
AD724JR
0°C to +70°C 16-Lead SOIC
R-16
R-16
R-16
AD724JR-REEL 0°C to +70°C 16-Lead SOIC
AD724JR-REEL7 0°C to +70°C 16-Lead SOIC
AD724-EB
Evaluation Board
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD724 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
REV. B
–3–
