Acutechnology Semiconductor Inc.
AQ8211
Ordering Information
Operating Tj
%Tol
PKG Type
VOUT
Wrap
Ordering Number
Device
AQ8211
AQ8211
AQ8211
AQ8211
-40C˚ ≤ 125C˚
-40C˚ ≤ 125C˚
-40C˚ ≤ 125C˚
-40C˚ ≤ 125C˚
1.0
1.0
1.0
1.0
SOT-23-5
SOT-23-5
SOT-23-5
SOT-23-5
1.8V
2.5V
3.3V
ADJ
T&R
T&R
T&R
T&R
AQ8211AY-M5-18-TRL
AQ8211AY-M5-25-TRL
AQ8211AY-M5-33-TRL
AQ8211AY-M5-AJ-TRL
Note: The TRL parts are Lead Free and RoHS compliant.
Absolute Maximum Ratings
Stress greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. These stress ratings only, and functional operation of the device at these or any conditions beyond
those indicated under recommended Operating Conditions is not implied. Exposure to “Absolute Maximum
Rating” for extended periods may affect device reliability. Use of standard ESD handling precautions is
required.
Parameter
Value
Units
Maximum VIN
18
18
Volts
Volts
Maximum VENABLE
Power Dissipation (Internally limited)
Maximum Junction Temperature
Operating Junction Temperature Range
Storage Temperature Range
150
-40C˚ ≤ 125C˚
-65 to 150
300
°C
°C
°C
°C
Lead Temperature (Soldering, 4 sec.) SOT- 23-5 package
Thermal Management
Typical
Value
Thermal Resistance (Junction to Ambient)
Units
SOT-23-5 (minimum foot print)
220
°C/W
Typical
Value
Thermal Resistance (Junction to Ambient)
Units
SOT-23-5 (Soldered to 1 in2 1 oz. copper PCB)
170
°C/W
www.acutechnology.com
3
Rev. 2.1 January 22, 2006
ACUTECH [ ACUTECHNOLOGY SEMICONDUCTOR ]
