0.27
A CURRENT CONSUMPTION VOLTAGE DETECTOR WITH DELAY FUNCTION (EXTERNAL DELAY TIME SETTING)
Rev.5.1_03
S-1009 Series
Timing Charts
1. Nch open-drain output product
VDD
Release voltage (VDET
)
Hysteresis width
Detection voltage (VDET
)
(VHYS
)
Minimum operation voltage
VSS
R
VDD
100 k
CD OUT
VSS
VDD
V
Output from OUT pin
VSS
tD
Figure 12
2. CMOS output product
VDD
Release voltage (VDET
)
Hysteresis width
Detection voltage (VDET
)
(VHYS
)
VDD
Minimum operation voltage
VSS
CD OUT
VSS
V
VDD
Output from OUT pin
VSS
tD
Remark When VDD is the minimum operation voltage or less, the output voltage from the OUT pin is indefinite
in the shaded area.
Figure 13
11
