FEDL87V2107-01
OKI Semiconductor
ML87V2107
#Valid data signal
IHS
NDTP[3:0]+1
NRDTP[3:0]
(DTPSL=0)
NDTP[3:0]+1
NRDTP[3:0]
(DTPSL=1)
#: Internal signal
Figure F2-1-7 (2) Vertical Blanking Noise Status Detection timing (NDTC = 1)
IVS
#IF
Field A
Field A
Field B
Field B
[NRDTF = 0: detection by field A]
Noise status
detection timing
[NRDTF = 1: detection by field B]
Noise status
detection timing
Figure F2-1-7 (3) Detection Field Based on NRDTF
Table F2-1-7 (1) Vertical Blanking Sample Noise Detection Settings
NRDTON
0
Noise detection
Stopped (previously
detected data is maintained)
Operating
1
Table F2-1-7 (2) Noise Detection Field Settings
NRDTF
Noise detection field
Field A
0
1
Field B
Table F2-1-7 (3) Blanking Period Noise Detection Line Settings
NDTC
Noise detection line
1 line set at the NRDTP[2:0] position
Multiple lines (a maximum of 8 lines) from the line after the last
valid line to NRDTP[2:0]
0
1
Table F2-1-7 (4) Noise Detection Value Select Settings
YNAMS
Noise detection value
CNAMS
0
1
8-frames average
Single frame
51/152
