2.1.5 Noise Reduction Stop Setting
Noise reduction can be forcibly stopped by setting NROFF (SUB:48h-bit[0]) on the I2C-bus interface.
However, data can be written into the memory even while noise reduction is stopped.
Table F2-1-5 NROFF Setting
NROFF
Noise Reduction
Operated
0
1
Stopped
2.1.6 Noise Reduction Demo Mode Setting
By setting NRDEMO[2:0] (SUB:48h-bit[2:0]), a screen can be split as shown in Figure F2-1-6 and noise
reduction function can be confirmed as demo mode or the I2C-bus interface.
However, the demo mode does not work when noise reduction is stopped by setting NROFF = 1.
Table F2-1-6 NRDEMO Setting
NRDEMO
NROFF
Left side of screen
Right side of screen
[2]
0
[1]
0
[0]
0
0
1
0
0
0
NR setting value
Stop NR
NR setting value
Stop NR
X
X
X
1
X
X
1
X
1
Stop NR
NR setting value
Adaptive NR
0
NR Setting value
NR Setting value
0
0
Adaptive 2DNR
Left side area
of screen
Right side area
of screen
Figure F2-1-6 Noise Reduction Demo Screen
