Bulkhead Receptacle/Solder Cup Terminal
Bulkhead Receptacle Plug - Front Mount
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
Brass Shell
B1351Q1-ND3G-50
B1351Q2-NT3G-75
N/A
N/A
Nickel
Nickel
Delrin
Teflon
50
75
N/A
N/A
Remark: 4.5 [.177] Max. panel thickness
Bulkhead Receptacle Jack - Front Mount
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
L1 = 3.2 [.126] Max. panel thickness, L = 26.7 [1.05]
B6351B1-ND3G-50
B6351B1-NT3G-50
N/A
N/A
Nickel
Nickel
Delrin
Teflon
50
50
N/A
N/A
OS-B713Z-ND3G-50
Die cast Body
N/A
Nickel
Delrin
50
N/A
B6351B1-ND3G-75
N/A
Nickel
Delrin
75
N/A
L1 = 6.5 [.256] Max. panel thickness, L = 30.0 [1.18]
B6351B2-ND3G-50
B6351B2-ND3G-75
N/A
N/A
Nickel
Nickel
Delrin
Delrin
50
75
N/A
N/A
L1 = 9.5 [.374] Max. panel thickness, L = 33.0 [1.30]
B6351B3-ND3G-50
B6351B3-ND3G-75
N/A
N/A
Nickel
Nickel
Delrin
Delrin
50
75
N/A
N/A
Bulkhead Receptacle Isolated Jack - Front Mount
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
B6651B1-NNYL3G-50
B6651B1-NNYL3G-75
N/A
N/A
Nickel
Nickel
ABS
ABS
50
75
N/A
N/A
Remark: 3.2 [.126] Max. panel thickness
Bulkhead Receptacle Isolated Jack - Rear Mount
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
B675100-001-NT3G-50
N/A
Nickel
Teflon
N/A
82
For Reversed Polarized connectors contact local Amphenol Sales Branch.
