Panel Jack Crimp Attachment for Flexible Cable and Direct Solder for Semi-Rigid Cable
Panel Crimp Jack - Standard Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
B6521A1-NT3G-1-50
B6521A1-ND3G-1A-50
B6521A1-NT3G-3-50
B6521A1-NT3G-3-75
01
01A
03
Nickel
Nickel
Nickel
Nickel
Teflon
Delrin
Teflon
Teflon
50
50
50
75
4
3 or 4
4
03
4
Remark: 5.0 [.197] Max. panel thickness
Assembly Instruction J - page 218
Panel Crimp and Solder Jack - Miniature and Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
B6521E1-NT3G-5-50
B6521F1-NT3G-5A-50
B6521F1-ND3G-6-75
B6581A1-N/3GT3G-10-50
B6581A1-N/3GT3G-11-50
05
05A
06
10
11
Nickel
Nickel
Nickel
Nickel/Gold Teflon
Nickel/Gold Teflon
Teflon
Teflon
Delrin
50
50
75
50
50
9
9
9
N/A
N/A
Remark: 5.0 [.197] Max. panel thickness
Assembly Instruction E - page 213
Assembly Instruction J - page 218
78
For Reversed Polarized connectors contact local Amphenol Sales Branch.
