Printed Circuit Board Connectors
Straight Jack for P.C. Board
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
MCX6251B1-NT30G-50
N/A
N/A
Nickel
Nickel
Teflon
Teflon
50
50
N/A
N/A
MCX6251B3-NT30G-50
2.92mm [.115”] LEGS
MCX6251B1-3GT30G-50
N/A
N/A
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
MCX6251B3-3GT30G-50
2.92mm [.115”] LEGS
MCX6251B4-NT30G-50
N/A
N/A
Nickel
Gold
Teflon
Teflon
50
50
N/A
N/A
Surface Mount
MCX6251B4-3GT30G-50
Surface Mount
Note: For 75 ohm connector change -50 to -75
