MCX Coaxial Connectors
Interface mating dimensions
Plug
Letter
Millimeters [Inches]
Maximum
Minimum
A
B
C
D
E
F
0.48 [.019]
2.00 [.079]
3.66 [.144]
0.00
0.53 [.021]
2.07 [.082]
3.76 [.148]
0.30 [.012]
3.20 [.126]
-
2.81 [.111]
4.16 [.164]
2.81 [.111]
G
3.20 [.126]
Jack
Letter
Millimeters [Inches]
Maximum
Minimum
A
B
C
D
E
F
1.80 [.071]
3.43 [.135]
3.61 [.142]
2.31 [.091]
2.61 [.103]
4.00 [.158]
0.75 [.030]
1.97 [.078]
3.48 [.137]
3.75 [.148]
2.79 [.110]
2.79 [.110]
4.12 [.162]
0.85 [.033]
G
18
Note: 1. I.D. to meet VSWR and Contact Resistance when mated with .48/.53 mm Dia. Pin.
