UT63M Single Channel MIL-STD-1553 Monolithic Transceiver
UT63M
*
*
*
*
*
Radiation:
5
=
=
1E5 rads(Si)
None
-
Lead Finish:
(A)
(C)
(X)
=
=
=
Solder
Gold
Optional
Screening:
(C)
(P)
=
=
Military Temperature
Prototype
(Q)
(V)
=
=
QML-Q
QML-V
Package Type:
(P) 24-pin DIP
=
Device Type Modifier:
105
107
=
=
+\-15V, Idle low
+\- 12V, Idle Low
Notes:
1. Lead finish (A, C, or X) must be specified.
2. If an “X” is specified when ordering, part marking will match the lead finish and will be either “A” (solder) or “C” (gold).
3. Military Temperature range devices are burned-in and are tested at -55°C, room temperature, and 125°C. Radiation characteristics are neither tested
nor guaranteed and may not be specified.
4. Devices have prototype assembly and are tested at 25°C only. Radiation characteristics are neither tested nor guaranteed and may not be specified. Lead
finish is at UTMC’s option and an “X” must be specified when ordering.
5. The 63M105 only may be ordered with 1E5 rads(Si) total dose. Co60 testing is required. Contact factory for details.
6. SEU and neutron irradiation limits will be added when available.
21
