CY545 Stepper System Controller
www.ControlChips.com
General Command Functions and Special Features
•
Parallel command interface with two line handshake, compatible with CY233 network
communications controller.
•
•
Serial command interface with fixed or adaptive baud rate selection.
Support for up to 64K of optional external command memory implemented as RAM,
ROM, EPROM, or EEPROM.
•
•
Support for optional external setting of parameter values, through standard thumbwheel
switches.
Selectable display for output messages from standard serial, standard parallel, or CY233
interfaces, plus special support for a parallel HP HDSP-211x LED display, or a CY325
based serial LCD display.
•
User controlled, multi-purpose I/O lines, for:
•
•
•
•
set and clear bit functions
test bit and branch functions
wait for bit value functions
automatic home seek functions
Prototyping Board Support
The CYB-545 Prototyping board implements most of the available features of the CY545
Stepper System Controller. A more complete description may be found in the chapter on
Prototyping Support.
