Absolute Maximum Ratings
Parameter
Symbol
VT
Value
Unit
V
Voltage on any pin relative to Vss
Supply voltage relative to Vss
Short circuit output current
Power dissipation
-0.5 to + 4.6
VCC
IOUT
PD
-0.5 to + 4.6
50
V
mA
W
1.0
Operating temperature
TOPT
TSTG
0 to + 70
-55 to + 125
°C
°C
Storage temperature
Recommended DC Operating Conditions
Parameter/Condition
Symbol
3.3 Volt Version
Unit
Min
3.0
Typ
3.3
Max
Supply Voltage
VCC
VIH
VIL
3.6
VCC + 0.3
0.8
V
V
V
Input High Voltage, all inputs
Input Low Voltage, all inputs
2.0
-
-
-0.3
Capacitance
Ta = 25°C, V = 3.3V ±10 %, f = 1MHz
CC
Parameter
Symbol
CI1
Typ
-
Max
Unit
pF
Note
Input capacitance (Address)
5
7
7
1
1
Input capacitance (RAS, CAS, OE, WE)
CI2
-
-
pF
pF
Output capacitance
(Data-in, Data-out)
CI/O
1, 2
Note: 1. Capacitance measured with effective capacitance measuring method.
2. RAS, CAS = V to disable Dout.
IH
Rev.1
Page7
