The operating instructions mentioned here are partial abstracts
from the Operating Instruction Manual. The page numbers of
the Operating Instruction Manual remein as in the manual.
SECTION 1
GENERAL
Use of the tilt-swivel
Precautions
Identifying parts and controls
This monitor can be adjusted within the angles shown below. To
find the center of the monitor’s turning radius, align the center of
the monitor’s screen with the centering dots on the stand.
See the pages in parentheses for further details.
Warning on power connections
•
Use the supplied power cord. If you use a different power cord,
be sure that it is compatible with your local power supply.
For the customers in the UK
Hold the monitor at the bottom with both hands when you turn it
horizontally or vertically. Be careful not to pinch your fingers at
the back of the monitor when you tilt the monitor up vertically.
Front
Rear
If you use the monitor in the UK, be sure to use the supplied UK
power cable.
MENU
RESET
AC IN
Example of plug types
90˚
15˚
MENU
RESET
90˚
5˚
for 100 to 120 V AC for 200 to 240 V AC for 240 V AC only
•
•
Before disconnecting the power cord, wait at least 30 seconds
after turning off the power to allow the static electricity on the
screen’s surface to discharge.
After the power is turned on, the screen is demagnetized
(degaussed) for about 5 seconds. This generates a strong
magnetic field around the screen which may affect data stored
on magnetic tapes and disks placed near the monitor. Be sure to
keep magnetic recording equipment, tapes, and disks away
from the monitor.
Centering dots
1 RESET button (page 12)
4 AC IN connector (page 6)
This button resets the adjustments to the factory settings.
This connector provides AC power to the monitor.
2 Control button (page 9)
5 Video input connector (HD15) (page 6)
This connector inputs RGB video signals (0.700 Vp-p,
positive) and sync signals.
The control button is used to display the menu and make
adjustments to the monitor, including brightness and contrast
adjustments.
GB
The equipment should be installed near an easily accessible
outlet.
1
2 3 4
5
3 1 (power) switch and indicator (pages 7, 13, 16)
This button turns the monitor on and off. The power indicator
lights up in green when the monitor is turned on, and either
flashes in green and orange, or lights up in orange when the
monitor is in power saving mode.
Installation
6
7
8
9
10
Do not install the monitor in the following places:
11 12 13 14 15
•
on surfaces (rugs, blankets, etc.) or near materials (curtains,
draperies, etc.) that may block the ventilation holes
near heat sources such as radiators or air ducts, or in a place
subject to direct sunlight
•
Pin No.
Signal
1
2
Red
•
•
•
•
in a place subject to severe temperature changes
in a place subject to mechanical vibration or shock
on an unstable surface
near equipment which generates magnetism, such as a
transformer or high voltage power lines
Green
(Sync on Green)
3
Blue
4
ID (Ground)
DDC Ground*
Red Ground
Green Ground
Blue Ground
–
•
near or on an electrically charged metal surface
5
Maintenance
6
•
Clean the screen with a soft cloth. If you use a glass cleaning
liquid, do not use any type of cleaner containing an anti-static
solution or similar additive as this may scratch the screen’s
coating.
7
8
9
•
•
Do not rub, touch, or tap the surface of the screen with sharp or
abrasive items such as a ballpoint pen or screwdriver. This type
of contact may result in a scratched picture tube.
Clean the cabinet, panel and controls with a soft cloth lightly
moistened with a mild detergent solution. Do not use any type
of abrasive pad, scouring powder or solvent, such as alcohol or
benzene.
10
11
12
13
14
15
Ground
ID (Ground)
Bi-Directional Data (SDA)*
H. Sync
V. Sync
Data Clock (SCL)*
Transportation
*
DDC (Display Data Channel) is a standard of VESA.
When you transport this monitor for repair or shipment, use the
original carton and packing materials.
4
