Real Time Clock Alarm Minutes Register
This register contains the alarm minutes value. See Table 47.
Table 47. Real Time Clock Alarm Minutes Register (RTC_AMIN = 00E9h)
Bit
7
X
6
X
5
X
4
X
3
X
2
X
1
X
0
X
Reset
CPU Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Note: X = Unchanged by RESET; R/W = Read/Write.
Binary-Coded-Decimal Operation (BCD_EN = 1)
Bit
Position
Value Description
[7:4]
0–5
The tens digit of the alarm minutes value.
ATEN_MIN
[3:0]
0–9
The ones digit of the alarm minutes value.
AMIN
Binary Operation (BCD_EN = 0)
Bit
Position
Value
Description
[7:0]
00h–3Bh The alarm minutes value.
AMIN
