MVTX2801
Data Sheet
Bit [1:0]:
•
Port member selection for Trunk 0 and 1 in unmanaged mode (Default 2'b00)
- 00 - Only trunk group 0 is enable. Port 0 and 1 are used for trunk group0
- 01 - Only trunk group 0 is enable. Port 0,1 and 2 are used for trunk group0
- 10 - Only trunk group 0 is enable. Port 0,1,2 and 3 are used for trunk group0
- 11 - Trunk group 0 and 1 are enable. Port 0, 1 used for trunk group0, and port 2 and 3 are used for
trunk group1
10.4.2 TX_AGE - Tx Queue Aging timer
2
I C Address: h03B;Serial Interface Address:h312
2
Accessed by serial interface and I C (R/W)
7
6
5
0
Tx Queue Agent
Bit[4:0]:
Bit[5]:
•
•
•
Unit of 100ms (Default 8). Disable transmission queue aging if value is zero.
Must be set to '0'
Reserved
Bit[7:6]:
10.5 Group 4 Address - Search Engine Group
10.5.1 AGETIME_LOW - MAC address aging time Low
2
I C Address h03C; Serial Interface Address:h400
2
Accessed by serial interface and I C (R/W)
Bit [7:0] Low byte of the MAC address aging timer. (Default 2c)
Mac address aging is enable/disable by boot strap T_D[9].
10.5.2 AGETIME_HIGH -MAC address aging time High
2
I C Address h03D; Serial Interface Address h401
2
Accessed by serial interface and I C (R/W)
Bit [7:0]: High byte of the MAC address aging timer. (Default 00)
Aging time is based on the following equation:
{AGETIME_HIGH,AGETIME_LOW} X (# of MAC entries X100µsec)
Note: the number of entries= 66K when T_D[5] is pull down (SRAM memory size = 512K) and 34K when T_D[5] is
pull up (SRAM memory size = 256K).
37
Zarlink Semiconductor Inc.
