YMF724F
46-47h: Subsystem ID Write Register
Read / Write
Default: 000Dh
Access Bus Width: 16-bit
b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
Subsystem ID Write
b[15:0] ........Subsystem ID Write Register
This register sets the Subsystem ID that is read from 2E-2Fh (Subsystem ID register).
The default value is the DS-1 Device ID, 000Dh. IHVs must change this ID to their ID in the BIOS
POST routine.
In case EEPROM connects externally, this register is invalid, and do not reflect to Subsystem ID.
48-49h: DS-1 Control Register
Read / Write
Default: 0001h
Access Bus Width: 8, 16, 32-bit
b15
b14
b13
b12
b11
b10
b9
-
b8
-
b7
-
b6
-
b5
-
b4
-
b3
-
b2
-
b1
b0
-
-
-
-
-
-
XRST CRST
b0................CRST: AC’97 Software Reset Signal Control
This bit controls the CRST# signal.
“0”: Inactive (CRST#=High)
“1”: Active (CRST#=Low)
(default)
b1................XRST: Local Device Software Reset Signal Control
This bit controls the XRST# signal.
“0”: Inactive (XRST#=High)
“1”: Active (XRST#=Low)
(default)
4A-4Bh: DS-1 Power Control Register
Read / Write
Default: 0000h
Access Bus Width: 8, 16, 32-bit
b15
b14
b13
b12
b11
b10
b9
b8
b7
-
b6
-
b5
b4
b3
b2
b1
b0
PR7
PR6
PR5
PR4
PR3
PR2
PR1
PR0
PSN PSL1 PSL0 DPLL1 DPLL0 DMC
b0................DMC: Disable Master Clock Oscillation
Setting this bit to “1” disables the oscillation of the Master Clock (24.576 MHz).
“0”: Normal
“1”: Disable
(default)
b1................DPLL0: Disable PLL0 Clock Oscillation
Setting this bit to “1” disables the oscillation of PLL for the Legacy Audio function.
“0”: Normal
“1”: Disable
(default)
