WM8983
Product Preview
Right DAC output to right output
R51
0
1
DACR2RMIX
BYPR2RMIX
1
0
mixer
Right channel
output mixer
control
0 = not selected
1 = selected
Right bypass path (from the right
channel input PGA stage) to right
output mixer
0 = not selected
1 = selected
4:2
BYPRMIXVOL
000
Right bypass volume control to
output channel mixer:
000 = -15dB
001 = -12dB
010 = -9dB
011 = -6dB
100 = -3dB
101 = 0dB
110 = +3dB
111 = +6dB
5
AUXR2RMIX
0
Right Auxiliary input to right channel
output mixer:
0 = not selected
1 = selected
8:6
AUXRMIXVOL
000
Aux right channel input to right mixer
volume control:
000 = -15dB
001 = -12dB
010 = -9dB
011 = -6dB
100 = -3dB
101 = 0dB
110 = +3dB
111 = +6dB
R3
2
3
LMIXEN
RMIXEN
0
0
Left output channel mixer enable:
0 = disabled
Power
management
3
1 = enabled
Right output channel mixer enable:
0 = disabled
1 = enabled
Table 31 Left and Right Output Mixer Control
PP Rev 1.1 August 2005
48
